AC-602 6×6mm 720P AHD camera head for OEM devices with existing AHD input. Built for compact inspection tools, dry equipment viewing, portable monitor kits, and DVR retrofit projects.
Goobuy AC-602 is a 6×6mm 720P AHD camera head for OEMs and system integrators who already have an AHD monitor, AHD DVR, RCA/BNC input, or coax-based host device and need a smaller low-latency camera for compact inspection tools, portable maintenance displays, dry equipment internal viewing, or retrofit analog HD video systems.
It is designed for real-time operator viewing, not AI image processing, USB software capture, IP camera streaming, MIPI integration, or high-resolution machine vision. For Customer who need to keep an existing AHD video architecture but reduce the camera head size, AC-602 provides a practical board-level camera option that can be evaluated with project-specific lens, FOV, cable, connector, and mechanical integration requirements.
Many OEMs and system integrators do not need a new camera system from zero. They already have an AHD monitor, AHD DVR, coax cable, 12V power design, or portable inspection display.
Their real problem is more specific:
the existing camera head is too large for the new mechanical space.
Goobuy AC-602 is designed for this type of project. It helps engineers keep the existing AHD video path while reducing the camera head to a 6×6mm board-level module.
This makes AC-602 suitable for compact inspection tools, handheld maintenance displays, dry equipment internal viewing devices, portable AHD monitor kits, and retrofit analog HD video systems where low-latency live view is more important than AI processing or software image capture.
In many industrial service tools and embedded live-view devices, the screen, DVR, power system, and video cable architecture are already defined. The project is blocked because the current camera head cannot fit into:
AC-602 helps solve that specific engineering problem:
Keep the AHD monitor or DVR. Keep the coax-based video path. Replace the bulky camera head with a 6×6mm AHD module.
This is why AC-602 is not positioned as a general camera module. It is positioned as a compact analog HD camera head for buyers who already have a host device and need a smaller visual access point.
screenshot compressed picture when 6*6mm AHD camera module made video and worked in daytime, July, 2024
( the following image had been compressed much because of website design request)
Many handheld inspection tools, service devices, and compact industrial terminals fail mechanical integration because the camera head cannot fit into the available space.
AC-602 provides a 6×6mm board-level camera head for applications where the available mounting area is very limited.
If your product already uses an AHD monitor, AHD DVR, RCA/BNC input, or coax cable, changing to USB or IP may create unnecessary redesign work.
AC-602 allows you to evaluate a smaller camera head while keeping the existing AHD architecture.
For live operator viewing, USB drivers, SDK integration, PC software, Ethernet settings, streaming delay, and network maintenance may not be needed.
AC-602 is intended for simple real-time viewing through an AHD-compatible host device.
Some maintenance and inspection tools are used by technicians who only need a clear real-time view of a hidden area.
They do not need AI analysis, measurement algorithms, or computer vision capture. They need a small, stable, low-latency camera head connected to a display.
AC-602 is suitable for handheld industrial inspection monitors where the screen and video input are already defined, but the camera head must be much smaller.
Typical buyer pain points:
How AC-602 helps:
Some projects already have an AHD DVR, coax cable, display, and power design. The only problem is that the current camera head is too large for a new enclosure or inspection position.
Typical buyer pain points:
How AC-602 helps:
AC-602 can be used inside dry and protected equipment where technicians need to view hidden areas during service, setup, or maintenance.
Typical buyer pain points:
How AC-602 helps:
Important note:
AC-602 is a board-level camera module. It is not an outdoor waterproof camera by itself. Wet, dusty, washdown, or outdoor environments require a protective housing or another waterproof camera option.
AC-602 can be evaluated for portable inspection kits that use a small AHD monitor and a compact camera head for field service or maintenance viewing.
Typical buyer pain points:
How AC-602 helps:
Technical Specifications
| Item | Specification |
|---|---|
| Model | AC-602 |
| Camera Head Type | Board-level AHD camera module |
| Board Size | 6×6mm |
| Output Interface | AHD analog HD |
| Resolution | 720P@30fps |
| Video Format | PAL standard, NTSC optional |
| Lens / FOV | 120° standard, or 90° optional by project |
| Video Connection | AHD RCA / BNC connection discussion |
| Cable Length | 20cm–2m or project-based configuration |
| Power Supply | 12V |
| Current | Approx. 50mA |
| Application Type | Low-latency live-view camera head |
| Best Host Devices | AHD monitor, AHD DVR, coax-based analog HD device |
| Custom Options | Lens, FOV, cable, connector, video format, mechanical integration |
The 6×6mm size refers to the board-level camera module size. The final mechanical envelope may be larger depending on:
For tool-tip integration or narrow cavity projects, please send your available space drawing, required camera direction, cable route, and mounting method. Goobuy can help check whether AC-602 can fit your device or whether a different camera structure is more suitable.
AC-602 is designed for real-time live viewing, not high-detail machine vision.
If you are unsure whether 720P is enough, please send your target object size, working distance, viewing area, lighting condition, and what the operator needs to identify.
AC-602 may not be the right camera if your project requires:
If your project falls into one of these categories, Goobuy can recommend another USB, AHD, waterproof, low-light, or global shutter camera module instead.
it can work with our 7/10inch monitor display together as one portable miniature industrial endoscope camera too
NDAA Compliance Statement:
"This product is manufactured in compliance with the National Defense Authorization Act (NDAA) Section 889."
Yes. AC-602 is designed for this type of retrofit or product upgrade project. If your host device already supports AHD video input, the 6×6mm camera head can be evaluated as a smaller replacement for a bulky camera module.
Before sampling, confirm your monitor input, supported AHD resolution, PAL/NTSC format, connector, power supply, available camera space, cable route, and required FOV.
In many live-view tools, yes. AHD can send video directly to an AHD monitor or DVR without UVC drivers, SDK integration, PC software, or network configuration.
If your product only needs low-latency operator viewing, AC-602 may be simpler than USB. If your product needs image capture, AI analysis, frame control, or software processing, a USB camera is usually more suitable.
That is one of the best-fit use cases for AC-602. It can help keep the existing AHD DVR, coax wiring, and display architecture while reducing the camera head size.
Compatibility still depends on PAL/NTSC format, connector wiring, cable length, power supply, grounding, and the DVR’s AHD input support. Testing with your actual DVR or monitor is recommended before custom configuration.
Not always. A 120° lens is useful when the camera is very close to the target and the operator needs a wide view. However, if the target is farther away or the operator needs more detail, a narrower FOV may be better.
Goobuy can help evaluate lens angle based on working distance, cavity size, target size, image detail requirement, and the viewing area the operator needs to see.
