Product Overview

Novel IP67 Outdoor USB Camera UC-531 is designed for reliability in the toughest environments. Equipped with a robust metal enclosure, IP67 waterproof rating, and integrated 18 infrared LEDs, this camera delivers 1080p video performance even in rain, dust, or complete darkness,this camera offers weatherproof and dustproof protection for industrial, marine, and smart city applications. Its plug-and-play USB interface ensures easy integration with PC, Linux, Jetson Nano, or Raspberry Pi systems



Key Features of rugged usb camera for outdoor industrial

✅ IP67-Rated Waterproof & Dustproof

Operates reliably in rain, snow, and dusty industrial settings

✅ Robust Metal Housing

Shockproof, heat-resistant, and corrosion-resistant build

✅ with LED light to strength night vision

✅ USB 2.0/Type-C Interface

Easy integration with standard systems and edge devices

✅ Wide Lens Selection

Supports 70-110 degree lens ; optional wide-angle or infrared night vision

✅ Low-Power Consumption

Efficient for 24/7 embedded use

Use Cases & Industry Applications

Application Scenario                              Industry/Target User

Smart Farming Machine Vision              Agricultural Equipment Manufacturers

Outdoor Industrial Equipment               Heavy Machinery & Automation Integrators

Industrial vehicle                                    Front forwarding or rear view, DIY installation

Perimeter Surveillance & Smart Cities   Security Integrators & Infrastructure Firms

Marine Equipment Monitoring              Maritime Electronics & ROV Providers

Construction Site Observation              Safety & IoT Deployment Companies

Waste Facility Monitoring                     Environmental System Builders



1	waterproof	IP67 meanwhile 18pcs LED night vision light
2	working environment	-30℃～70℃；humidity at20%～80%
3	Unit pixel	2.8 x 2.8 µm
4	Video Resolution	1920（H)*1080(V)
5	Video output	YUV2/JEPG
7	Working voltage	+5V
8	Working currency	Less than 100mA（IR off）
9	Minimum illumination	0.5 lux
10	White balance	Auto
11	WDR	support（95DB）
11	Lens	3.6mm
13	FOV	70 degree
14	Supports driveless protocols	USB Video Class（UVC）
15	Operating System	Widows2000/XP/WIN7/Vista/Linux with UVC
16	Interface protocol	USB2.0
17	Cable Length	1.5 meter
18	Infrared fill light	Auto
19	Infrared wavelength	NO
20	Night vision turns on illumination	5Lux
21	Night view image	White and Black Image



FAQ

Q1: What does IP67 mean?
A: The camera is fully dust-tight and can withstand immersion in 1 meter of water for up to 30 minutes.

Q2: Is it compatible with Jetson or Raspberry Pi?
A: Yes. It is UVC-compliant and works directly with Jetson Nano, Xavier, and Raspberry Pi OS. GStreamer and ffmpeg examples are available.

Q3: Can I choose different IR options?
A: Yes, 850 nm (strong illumination) or 940 nm (invisible light for stealth monitoring).

Q4: Can the USB cable be customized?
A: Default 1.5 m. Optional longer cables, waterproof connectors, and custom cable glands are available.



Your local Target Customers

1.     Industrial Equipment Manufacturers

Building rugged systems for outdoor use: compressors, mining systems, industrial robots

2.     AGV & Robotics Companies

Those creating mobile platforms for industrial/warehouse/outdoor use

3.     Agritech & Smart Farming Solution Providers

Needing durable cameras on machines or weather stations

4.     Maritime Technology Providers

Creating marine monitoring, docking cameras, or ROVs (Remotely Operated Vehicles)

5.     OEMs for Security & Surveillance Systems

Requiring waterproof modules for custom outdoor camera builds

6.     Automation System Integrators

Who design IP-based machine vision or inspection systems in moisture-prone environments

7.     System Builders for Smart City Infrastructure

Traffic monitoring, smart bus stops, outdoor kiosks requiring weatherproof vision systems

8.     Retailers or Distributors of Industrial Components

Focused on ruggedized components for European/USA markets



About Shenzhen Novel Electronics Limited

We specialize in high-resolution Sony Omnivision Aptina Galaxycore custom-made USB camera modules, machine vision systems, night vision camera and micro embedded camera solutions. Trusted by clients across the USA, Europe, and Asia, we deliver reliable quality camera modules worldwide for industrial, medical, AI, Drone UAV, automotive, and robotic systems.
