The Goobuy AC-501 is a 15×15mm ultra-compact AHD camera module built around the Sony IMX323 2MP sensor. It outputs 1080P analog HD video with excellent low-light performance, near-zero latency, and strong EMI resistance, making it ideal for embedded devices, industrial machinery, robotics inspection systems, HVAC pipelines, and space-constrained applications. The AC-501 supports long-distance AHD transmission over coaxial cables and offers full OEM/ODM customization for lenses, cables, connectors, housings, and DVR integration.



Product Overview

The AC-501 is a 15x15mm mini AHD camera designed as a custom PCB board level camera for industrial and embedded integration. Powered by the Sony IMX323 sensor, it delivers 1080P AHD video with zero latency analog HD camera performance, making it ideal for substation panel AHD camera installations.

As an ODM embedded vision supplier, we provide full customization for board camera with custom lens options, cable lengths, housing, and integration to match specific OEM requirements. Compact in size (PCB 12×12 mm, holder 15×15 mm) and consuming only 12 V / 90 mA, this module is the ideal micro board camera for OEM customers who demand reliability, stability, and industrial-grade video transmission.

• Product: Mini 15×15mm Micro Low light AHD Camera with UTC function
• Sensor: Sony CMOS (IMX323)
• Output: AHD 1080P Analog Signal, direct connect with any standard AHD monitor and 2/4/8CH AHD DVR with same connector well
• Dimensions: 12×12mm PCB Board, Interchangeable Various M12 lens optional
• Features: Low-lux, Compact Size, Custom Cables/Lens/Mic/Waterproof Optional
• Applications: Industrial machines, Embedded Vision, Commercial Security Systems



Why Choose the Goobuy AC-501 Micro AHD Camera? (Unique Advantage)
• Sony IMX323 2MP sensor with high image clarity
• 1080P AHD output with extremely low latency
• Ultra-compact 15×15mm form factor for tight installations
• Excellent low-light performance for dark industrial environments
• Stable coaxial transmission up to hundreds of meters
• Driver-free, plug-and-play connection to AHD DVRs and monitors
• Highly reliable in dusty, vibrating, high-temperature or oily environments
• Suitable for embedded devices, industrial tools and maintenance systems
• Full OEM/ODM customization options (lens, cable, housings, connectors)



what difficulty or troubling problems it can solve in Embedded Vision Systems Applications?

Problems Solved:

• Miniature Vision for AI/ML at the Edge:
  • Problem: Developing compact embedded systems (e.g., drones, tiny robots, smart sensors, specialized medical devices) that require high-quality visual input for onboard AI/ML processing (object detection, facial recognition, navigation).
  • Solution: The 15x15mm size makes it ideal for these space-constrained platforms. The Sony IMX323 provides excellent image data for algorithms, and the M12 lens allows optimizing the FoV for specific AI tasks. AHD's low latency is crucial for real-time edge processing.
  •
• Custom Optical Path Integration:
  • Problem: Needing to design a custom optical system with precise control over focal length, depth of field, or distortion for a specialized embedded application (e.g., microscopy, specialized scanning).
  • Solution: The interchangeable M12 lens system is a perfect fit, allowing for rapid prototyping and fine-tuning of the optical path.
  •
• Robust Data Link for Integrated Systems:
  • Problem: Ensuring a stable and reliable video feed from the camera module to the embedded processor over a potentially custom or noise-prone internal connection.
  • Solution: Custom cable/connector options (Mini 4-pin for board-to-board, BNC for external connections if needed) and the inherent robustness of AHD help maintain signal integrity within complex embedded systems.
  •
• Low-Power Embedded Vision:
  • Problem: Minimizing power consumption for battery-powered or energy-sensitive embedded devices that require vision.
  • Solution: The AHD interface is generally simpler and can be more power-efficient for video transmission than a full IP stack in certain embedded contexts.



Special Demands Met:

• Ultimate Miniaturization: Core to many cutting-edge embedded vision designs.
• Developer Flexibility: The combination of sensor performance, M12 lens, and custom connectivity provides unparalleled flexibility for embedded system developers to tailor the vision subsystem precisely to their needs.
• Rapid Prototyping: Allows developers to quickly test different optical configurations during the design phase.
• Dedicated Vision Subsystem: Can serve as a self-contained, high-performance visual input unit for highly specialized embedded applications.



Technical Specifications

Model No.	AC-501-2MP-J
Sensor	SONY IMX323 CMOS 1/2.9” AHD
Resolution	1920*1080P@25FPS，PAL （NTSC is optional）
Output	AHD, RCA / BNC interface
FOV	90°, Pinhole lens, optional
Focus	Manual
White balance	Auto
Microphone	With Microphone
Dimension	Holder: 15*15mm
Length of cable	20cm~2M, standard 0.5M
Power	12V / 50mA, 12V / 90mA
Material	Plastic camera with metal lens
Temperature	-10~+65℃

The Goobuy AC-501 is a 15×15mm zero-latency Sony IMX323 AHD camera module delivering 1080P analog HD video over coaxial cable for embedded industrial equipment, kiosk integration, access control panels, HVAC inspection robots, ATM machines, smart vending systems, and OEM product customization.



other EFL Replaceable m12 lens available as following

A1, pinhole m12 lens

EFL 2.1/2.8/3.7/5/6/7/8/10/15/20/22/25/30/35/45/70mm

A2,  Flat normal m12 lens

1.08/1.39/1.44/1.56/1.7/1.8/2.1/2.8/3.6/4/6/8/9.9/12/16/25/50mm



Why Choose AHD (Analog High Definition) over USB?

• Zero Latency (<1ms): Unlike USB cameras which have encoding delays (100-300ms), this IMX323 AHD module transmits raw analog video instantly. Perfect for real-time teleoperation and driving assistance.

• Long Range Transmission: Supports reliable video transmission up to 300-500 meters over standard coaxial cable, whereas USB is limited to 3-5 meters.

• Cost-Effective Low Light: The Sony IMX323 sensor provides superior color night vision (0.01 Lux) at a fraction of the cost of digital STARVIS solutions



Frequently Asked Questions (FAQ)

1,How long this camera can work well?

AHD (Analog High Definition) supports 720P/1080P HD video over coaxial cable up to 500meter at most, ideal working distance is 200meter



2,  What customization options are available for OEM projects?

Goobuy offers customizable lenses, FOVs, cable lengths, connectors, housings, and optional DVR recording modules for professional integration.

Can I customize the lens or cable?
Yes, we support OEM customization for lens, cable length, housing, and connectors.as an ODM embedded vision supplier, we offer wide, telephoto, pinhole, and custom lens builds for your application.

Full OEM/ODM customization is offered, including M12 lens selection (various focal lengths and FOV), custom cable lengths from 100mm to 10m+, waterproof IP67 housing, and connector types (JST, Hirose, custom PCB pads).

3, Q: What types of M12 lenses can I use with this module?
A: It's compatible with a wide range of standard M12 (S-mount) lenses, allowing you to choose different focal lengths (e.g., wide-angle, standard, telephoto), apertures, and IR-cut filter options

4,  What advantages does the IMX323 micro AHD camera offer over USB and IP cameras?

The Goobuy AC-501 provides near-zero latency, high EMI resistance, and long-distance coax transmission, making it better suited for industrial environments where USB or IP networks are unstable.

AHD cameras provide uncompressed, zero-latency analog signal transmission over coaxial cables up to 500 meters. This sub-millisecond delay is critical for human-in-the-loop robotic teleoperation, where USB digital encoding latency could cause severe operational errors.



5,  Is Goobuy AC-501 camera suitable for embedded or space-limited equipment?

Yes. The 15×15mm camera head and 12×12mm PCB are optimized for confined spaces in industrial tools, inspection robots, and handheld devices.



6,  What is the maximum cable transmission distance for the AHD output?
A: The AHD signal can be reliably transmitted up to 300–500 meters over standard RG59 coaxial cable without signal degradation, making it far superior to USB cameras for long-run industrial installations.



7, What are the advantages of BNC vs. Mini 4-pin connectors?
A: BNC is a widely used, robust coaxial connector common in traditional CCTV, offering secure connections. Mini 4-pin is much smaller, ideal for compact integrations, providing power, video, and potentially control signals in a single, miniature plug. Your choice depends on space constraints and existing infrastructure.

8,  Can it connect to any AHD DVR or industrial monitor?

Yes. The AC-501 AHD camera outputs standard AHD video and works with nearly all AHD DVR systems, monitors, and portable inspection screens.

Yes. The AC-501 outputs a standard AHD 1080P analog signal that connects directly to any 2/4/8-channel AHD DVR using standard coaxial cable (BNC or custom connector options available). No additional converter or adapter is required.



Use Scenarios for Novel 15×15mm 2MP AHD Camera Module

1. Industrial Inspection and Monitoring

HVAC and Pipeline Inspection
The micro 15×15mm form factor makes it ideal for ducts, pipelines, ventilation shafts, and maintenance gear used by field technicians.

Use Case: Inspect machinery, pipelines, production lines, or other industrial equipment for wear, damage, or anomalies.

Application: Visual inspections in confined spaces where traditional cameras can't fit, such as pipelines, ducts, or machinery interiors.

Example: Used in robotic arms for automated quality control or inspection in harsh industrial environments.



2. Factory machines that need real-time operator view without USB or IP latency
    Elevator, HVAC, pipe and duct inspection tools with long cable distance
  HVAC & Pipeline Inspection Robots: the compact size and coaxial output make it the preferred module for miniature inspection crawlers used in HVAC   ductwork, sewer pipes, and industrial piping systems.
Industrial HMIs, access panels and embedded service tools.



3. Real-time human-in-the-loop teleoperation for hazardous environment robotics, surgical robot end-effector positioning, and long-range (up to 500m) agricultural machinery monitoring.



4. Automotive Diagnostics and Surveillance

Use Case: Used for vehicle inspection, diagnostics, or driver assistance systems.

Application: Provides video feedback in automotive diagnostic tools or serves as part of advanced driver-assistance systems (ADAS) in vehicles.

Example: Installed in vehicle inspection systems to check engine components or assist with reverse camera systems.



5. Engergy Security and Surveillance Systems

Use Case: Integrated into surveillance cameras or security monitoring systems, particularly in tight or discrete areas.

Application: Used for video surveillance in warehouses, factories, parking lots, and other spaces requiring discreet or unobtrusive monitoring.

Example: Installed in covert security cameras for industrial or commercial settings where space is limited.



6. Wearable & Handheld Inspection Devices

Use Case: Portable or wearable devices for hands-free inspections.

Application: Integrated into handheld inspection tools or wearable systems for professionals performing on-the-go visual inspections in tight spaces.

Example: Embedded in wearable inspection cameras used by maintenance teams for hands-free operations.



7,  Machine Monitoring and Diagnostics
Used inside industrial equipment housings for long-term monitoring of moving components, mechanical arms, and high-vibration systems.



Who Benefits Most from Goobuy Custom AHD Camera Module?

• CCTV System Integrators (USA-based): Needing flexible, high-performance AHD camera modules for custom security installations.
• OEMs & Product Developers: Seeking a miniature, high-quality AHD camera with customisable lens and connectivity options for new product lines.
• Industrial Automation Specialists: Designing bespoke vision systems for machinery, robotics, or process control.
• Engineering Consultancies: Requiring tailored camera solutions for unique project challenges and harsh environments (when housed appropriately).
• Advanced DIY & Robotics Enthusiasts: For high-end custom builds that demand specific camera performance and form factor.



Customer Feedback & Comments

⭐ “Perfect for Tight-Space Inspections”

“We’ve been using the 15×15mm AHD camera in our pipeline inspection robots. Its compact size allows it to fit into small, confined spaces where traditional cameras can’t go. The 1080P clarity is fantastic, even in dimly lit conditions.”

— Robotics Engineer, USA



⭐ “Reliable Performance for Automotive Inspections”

“We integrated the 15×15mm AHD camera into our diagnostic tools for automotive inspections. It’s incredibly compact and fits perfectly into tight engine compartments. The 1080P output allows us to spot even the smallest issues in real-time, reducing diagnostic time by over 25%.”

— Automotive Inspection Technician, UK



⭐ “A Powerful Yet Compact Solution for Robotics”

“The camera’s small size and high-definition video quality made it an ideal solution for our robotic arm vision system. We use it for object detection and real-time monitoring in our assembly line robots. The ease of integration and outstanding image clarity helped improve our system's efficiency.”

— Automation Solutions Provider, Japan



Why Choose shenzhen Novel Electronics limited?

• Specialized in custom PCB board level cameras and micro board camera for OEM solutions
• Full OEM/ODM service – lens, housing, cabling, firmware tuning
• Proven as an ODM embedded vision supplier for EU/US industrial clients
• High reliability with zero latency analog HD camera performance
